Weidun® 003 PE Fiberglass Bitumen Membrane
Weidun® 003 PE Fiberglass Bitumen Membrane is a flexible, resilient, non-woven fiberglass mat that is coated with polymer-modified bitumen and is smooth. It is a time-proven system that has been around for decades due to its reliable performance.
Uses:
- Roofing solutions in the industry
- Subway, tunnel, highway, bridge and etc
Data Sheet
Features & Benefits
Superior Durability
Strong, durable and manufactured to consistent dimensions
Lasting Value
Enjoy a zero-maintenance with a 20-year warranty for the quality you can trust
OEM Available
Offer superior performance based on your region's unique climate needs
Product Details
Weidun® 003 PE Fiberglass Bitumen Membrane is a flexible, resilient, non-woven polyester mat that is coated with polymer-modified bitumen and is smooth. After the installation of Weidun®003, a protective mortar-cement layer must be applied over the waterproofing layer to extend its service life.
Advantages
- Weidun Waterproofing has a full line of Weidun® 003 PE Fiberglass Bitumen Membrane.
- Excellent performance on vertical surface
- Specially formulated modified asphalt gives a lasting performance
- Easy to apply by torching
- Available guarantee of up to 15 years
Uses
Weidun® 003 PE Fiberglass Bitumen Membrane are perfect for waterproofing of roofs, basement, below-grounded structures, bridges and other structures.
Storage and Handling
To prevent damage, support rolls on end upright and store in a clean, dry location, covering as necessary to protect from environmental damage. Monitor environmental conditions during storage.
Technical Data Sheet
Property | Standard Minimum Valve | Weidun Value |
Thickness, mils (mm) | 45 | 45 |
Length min, meter(m) | 6 | 2 |
Soluble content, (g/m²） | >2900 | 3011 |
Tensile strength at 23℃ +/-2℃, (%) | >500 | 50 |
Tear strength at 23℃ +/-2℃, (%) | >150 | 169 |
Elongation at 23℃ +/-2℃, (%) | >30 | 45 |
Dimensional stability,(%) | 0.5 | 0.04 |
Low-temperature flexibility, at -35 ℃ | No crack | No crack |
Quality loss after heating condition,(%) | No flow | No flow |
Water penetration ( Maintain a water pressure of 1.5bar for 7days ) | Non-penetration | Non-penetration |
Weidun® 003 PE Fiberglass Bitumen Membrane is a flexible, resilient, non-woven polyester mat that is coated with polymer-modified bitumen and is smooth. After the installation of Weidun®003, a protective mortar-cement layer must be applied over the waterproofing layer to extend its service life.
