Weidun®LQ009 CrystallineWaterproofingCoatingisapowder-basedorliquidreactivematerial thatwaterproofsconcretethroughaprocessofcapillaryactionandchemicalreaction. Itsactivechemicalspenetrateintotheporesandcapillariesoftheconcrete.
Product Highlights
Strong, durable and manufactured to consistent dimensions
Enjoy a zero-maintenance with a 20-year warranty for the quality you can trust
Offer superior performance based on your region's unique climate needs
Weidun®LQ009 Crystalline WaterproofingCoatingisapowder-basedorliquidreactivematerialthatwaterproofsconcretethroughaprocessofcapillaryactionandchemicalreaction. Whenappliedtoaconcretesurface,itsactivechemicalspenetrateintothepores
andcapillariesoftheconcrete.Inthepresenceofmoisture,theyreactwithby-productsofcementhydrationtoforminsolublecrystallinestructuresthatpermanentlyblockthepassageofwater.
Weidun®LQ009 CrystallineWaterproofingCoating is designed for waterproofing basement floors, underground structures, and water tanks.
To prevent damage, maintain proper ventilation in the storage area and keep it in a clean, dry location, covering as necessary to protect it from environmental damage.
Monitor environmental conditions during storage, handling, and application.
| Property | Standard Minimum Valve | Weidun Value |
| Mortar impermeability pressure (with coating, 28d), (Mpa)
|
0.7 | 0.8 |
| Mortar impermeability pressure ratio (with coating, 28d), (%)
|
250% | 267% |
| Mortar impermeability pressure (without coating, 28d), (Mpa)
|
0.6 | 0.6 |
| Mortar impermeability pressure ratio (without coating, 28d), (%)
|
175 | 200 |
| Concrete impermeability pressure (with coating, 28d), (Mpa)
|
1.0 | 1.1 |
| Concrete impermeability pressure ratio (with coating, 28d), (%)
|
250 | 275 |
| Concrete impermeability pressure (without coating, 28d), (Mpa)
|
0.9 | 0.9 |
| Concrete impermeability pressure ratio (without coating, 28d), (%)
|
175 | 225 |
| Secondary impermeability pressure of coated concrete (56d), ) (Mpa)
|
0.8 | 0.8 |
| Parameter | Value |
|---|---|
| Pail Size | 25 L |
| Pail Height | 340.0 mm |
| Pail Diameter | 270.0 mm |
| Pail Weight | 25.0 kg |
| Pails per Pallet | 64 |
| Full Pallet Weight | 1.6 ton |
