Weidun®WD006 is more than just a simple moisture barrier. This sheet membrane is also a critical defensive layer for deep-seated basment structures. It utilizes a high-density polyethylene core with an integrated pressure-sensitive adhesive. This basement waterproofing system forms a full bond that eliminates any gaps between the waterproofing layer and the structural wall. The sheet ensures that the building’s envelope remains impervious to moisture ingress even under significant hydrostatic pressure.
Project-Based Insights
Hot year-round, 27–28°C. Wet season May–Nov with heavy rain (~2,000 mm). Dry season Dec–Apr. Abundant sunshine (~2,500 h). UV index very high, typically Aug to Sep.
Weidun has appointed the following regional distributors in Southeast Asia:
Matrix Chemical – Ho Chi Minh City, Vietnam
Tmassif Construction Chemical – Manila, Philippines
Weidun®WD006 offers a decisive technical edge here. The HDPE composition is naturally resistant to water-logging and biological decay common in humid, subterranean environments, growing fast in basement waterproofing in this area.
Humidity Resistance
Service Life
Desert climate, scorching summers over 40°C, mild winters. Extremely arid (~60 mm rain). Year-round intense sunshine (~3,900 h). UV index very high, reaching 8–11.
Weidun has appointed the following regional distributors in the Middle East:
Procare Building Supplies – Dubai, UAE
Izomaks – Riyadh, Saudi Arabia
Our HDPE membranes are engineered to act as a chemically inert barrier. Even if the surface temperatures are high during installation, this sheet remains structurally sound, providing a layer that’s resistant to corrosion to fully protect foundations against the aggressive desert ground conditions.
High Temperature Endurance
Water Pressure Ressistence
Mediterranean semi-arid climate, hot dry summers 26–27°C, mild wet winters (~317 mm rain). Abundant sunshine (~3,900 h). UV index high, 8–9 in summer.
Weidun has appointed the following regional distributors in North Africa:
Across the diverse terrains of North Africa, civil engineering projects require membranes that can handle soil movement and potential groundwater contaminants. Our HDPE sheet membrane is favored for its exceptional dimensional stability and chemical resistance.
Protection Excellent
Waterproof Integrity
Quick Product Guide
Everything contractors, architects, and project owners need to know before selecting this waterproofing system.
WD006 is a high-performance, cold-applied pre-poured waterproofing sheet. It utilizes a durable, high-density polyethylene (HDPE) backing.. The sheet is coated with a specialized pressure-sensitive adhesive layer and a unique weather-resistant protective coating. It is not the same as the traditional post-applied membranes that are stuck to the building. Rather, this membrane is a blind-side system.
Weidun®WD006 is primarily used for basement blind-side waterproofing in tight urban sites, tunnel and subway construction, and critical slab-on-grade projects. It is engineered for heavy-duty underground protection, high-performance civil engineering, and critical foundation sealing where it can protect structures from high-pressure groundwater and soil moisture.
HDPE pre-applied membrane installation requires a properly prepared substrate, correct membrane orientation, and secure fixing. First, clean the concrete surface and remove dust, debris, and sharp objects to ensure a smooth installation base. Next, place the membrane with the sand-coated surface facing upward to enhance bonding with the poured concrete. Finally, fix the membrane according to project requirements, carefully treating overlaps and details to create a continuous and reliable underground waterproofing system.
Why Choose US?
Each roll of this HDPE sheet is manufactured to surpass international standards for underground waterproofing and strength.
Weidun HDPE waterproofing membranes are tested according to relevant ASTM standards, including hydrostatic pressure resistance, tensile strength, tear resistance, and bonding performance requirements.
Achieves a peel strength of 1.5 N/mm to ensure the membrane and concrete become one.
Tested at 357 N/50mm to endure the extreme mechanical stresses of soil settling and structural shifting.
With an elongation at break of 400%, it easily bridges cracks caused by concrete shrinkage.
Maintains absolute watertightness under a constant pressure of 0.3 MPa for 120 minutes.
Products Comparison
This HDPE pre-applied sheet serves as the primary defense for the “blind side” of your foundation. It is installed before the concrete is poured to create an elastic, high-strength base that absorbs ground movement and prevents water from ever touching the structural concrete.
Weidun®️WD001 Smooth Bitumen Membrane uses hot-melt torch application.25 years life span (requires future repairs); HDPE ≈ 40 years.Compare with HDPE membrane, bitumen membrane system is significantly lower in material and installed cost.
Technical Performance
Metric | Weidun® WD006 (HDPE) | Weidun® SBS Modified Bitumen |
Material Type | Thermoplastic polyolefin | Modified bitumen (elastomer) |
Flexibility | High, especially at low temperatures | Good, but stiffens in cold |
Tensile Strength | Very high (typically > 25 MPa) | Medium to high (reinforced) |
Elongation | > 500% | 30 – 50% (reinforced) |
Installation | Pre-applied (blind-side); No flame | Torch-on/Self-adhesive; Requires flame |
Water Vapor Resistance | Excellent | Good but lower |
Durability | Life expectancy > 50 years (buried) | UV protection needed if exposed |
Environmental | Low VOC; Recyclable | Higher VOC; Non-recyclable |
Weidun®WD006 HDPE Pre-Applied Waterproofing Membrane is a high-performance, cold-applied blind-side system engineered to surpass international standards for critical underground and civil engineering protection. By utilizing mechanical bond technology that permanently fuses with poured concrete, it eliminates water tracking and delivers exceptional tensile strength, heavy-duty puncture resistance, and extreme chemical stability to safeguard foundations across diverse global climates.
Expert-Insight
Before deploying the pre-applied HDPE waterproofing membrane, comprehensive substrate preparation is mandatory. The structural excavation surface—whether a smooth mud slab, concrete blinding, or a shotcrete retaining wall—must be completely sound, uniform, and free of any sharp protrusions, loose gravel, or standing water.
Weidun’s Tip – For irregular lagging or rough shotcrete walls, installing a non-woven geotextile cushioning layer is highly recommended to eliminate the risk of puncturing the HDPE liner under immense lateral earth pressure.
Unroll the HDPE waterproofing sheets directly over the prepared substrate. For below-grade slab applications, ensure the sand-coated surface faces upward (towards the interior) to subsequently form an un-tearable mechanical bond with the poured concrete. For blind-side vertical walls, the membrane must be installed sequentially using targeted mechanical fastening. Secure the top edge and perimeter flanges with heavy-duty washers and metal fixings driven into the substrate.
With the underground waterproofing barrier firmly secured and all penetration details sealed, the site is ready for structural steel reinforcement. Workers must utilize plastic-capped rebar concrete spacers rather than sharp concrete blocks to prevent tearing the HDPE membrane during rebar positioning. Finally, proceed with the structural concrete pouring directly onto the pressure-sensitive, sand-coated side of the membrane. As the wet concrete matrix cures, it integrates completely with the sand particles, establishing a permanent anti-water-migration seal that eliminates any potential lateral water tracking.
Testimonials
Weidun’s HDPE membrane delivers exceptional long-term waterproofing below grade. Over years of heavy hydrostatic pressure, zero leaks occurred, backed by their superb remote guidance.
Minh Nguyen - Vietnam
Excellent durability! Our underground structures remain completely dry years after installing Weidun’s HDPE liner. Their consistent remote technical support brings great peace of mind
Admad Arif - Dubai
The temperature difference between day and night in our region is quite significant. However, the products of WEIDUN have withstood the test. Although the prices of these products are relatively high, they have indeed been flawless.
Saleh Abbas - Libya
During our initial communication, I was concerned that too many customization requests might be difficult to fulfill. However, WEIDUN Company has satisfied almost all of them.
Minh Nguyen - Vietnam
As a subcontractor, every time after the construction inspection, the main contractor is extremely satisfied with our product quality. This has been our sixth year of cooperation with WEIDUN.
Admad Arif - Dubai
The temperature difference between day and night in our region is quite significant. However, the products of WEIDUN have withstood the test. Although the prices of these products are relatively high, they have indeed been flawless.
Saleh Abbas - Libya
Production To Shipment
Choose the Right Products
Our product line is manufactured to match the specific technical demands of underground civil engineering and industrial roofing.
FAQ’s
A pre-applied HDPE membrane (such as Weidun® HDPE) is a heavy-duty thermoplastic sheet engineered for blind-side, below-grade waterproofing. Unlike traditional post-applied membranes, it features a unique sand-coated surface integrated with a pressure-sensitive adhesive layer. Installed before the steel reinforcement and concrete placement, the membrane faces the poured concrete matrix. As the concrete cures, it reacts chemically and mechanically with the adhesive layer, forming a continuous, permanent bond that effectively prevents any lateral water migration or tracking.
Engineered with high-density polyethylene resin, the membrane provides exceptional tensile strength, severe puncture resistance, and low permeability. It is built to withstand constant, heavy hydrostatic pressure in deep basements, retaining walls, and civil infrastructures. When properly installed with sealed self-adhesive overlaps and secured via perimeter (mechanical fastening) on vertical piles, it forms an impenetrable shield that blocks both liquid water and aggressive underground gas/chemical ingress.
No. Weidun®WD006 is a cold-applied system. The overlaps are typically sealed with self-adhesive strips or specialized welding. It is safer and faster to install in confined underground spaces.
